Essentials

Product Collection: Intel® Core™ Ultra Processors (Series 2)

Code Name:  Products formerly Arrow Lake

Vertical Segment: Desktop

Processor Number: 225F

Overall Peak TOPS (Int8): 19

CPU Specifications

Total Cores: 10

# of Performance-cores: 6

# of Efficient-cores: 4

# of Low Power Efficient-cores: 0

Total Threads: 10

Max Turbo Frequency: 4.9 GHz

Performance-core Max Turbo Frequency: 4.9 GHz

Efficient-core Max Turbo Frequency: 4.4 GHz

Performance-core Base Frequency: 3.3 GHz

Efficient-core Base Frequency: 2.7 GHz

Cache: 20 MB Intel® Smart Cache

Total L2 Cache: 22 MB

Processor Base Power: 65 W

Maximum Turbo Power: 121 W

Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes

AI Software Frameworks Supported by CPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

CPU Lithography: TSMC N3B

Supplemental Information

Embedded Options Available: No

Use Conditions: PC/Client/Tablet

Memory Specifications

Max Memory Size (dependent on memory type): 256 GB

Memory Types: Up to DDR5 6400 MT/s

Max # of Memory Channels: 2

ECC Memory Supported ‡: No

GPU Specifications

N/A

NPU Specifications

NPU Name‡: Intel® AI Boost

NPU Peak TOPS (Int8): 13

Sparsity Support: Yes

Windows Studio Effects Support: Yes

AI Software Frameworks Supported by NPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

Direct Media Interface (DMI) Revision: 4

Max # of DMI Lanes: 8

Intel® Thunderbolt™ 4: Yes

Scalability: 1S Only

PCI Express Revision: 5.0 and 4.0

PCI Express Configurations ‡: Up to 1×16+2×4, 2×8+2×4, 1×8+4×4

Max # of PCI Express Lanes: 24

Package Specifications

Sockets Supported: FCLGA1851

Thermal Solution Specification: PCG 2022C

Max Operating Temperature: 105 °C

Package Size: 45 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator: 3.5

Intel® Thread Director: Yes

Intel® Speed Shift Technology: Yes

Intel® Turbo Boost Technology ‡: 2.0

Intel® Hyper-Threading Technology ‡: No

Intel® 64 ‡: Yes

Instruction Set: 64-bit

Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States: Yes

Enhanced Intel SpeedStep® Technology: Yes

Thermal Monitoring Technologies: Yes

Intel® Volume Management Device (VMD): Yes

Security & Reliability

Intel® Threat Detection Technology (TDT): Yes

Intel® Active Management Technology (AMT) ‡: No

Intel® Standard Manageability (ISM) ‡: Yes

Intel® Remote Platform Erase (RPE) ‡: No

Intel® One-Click Recovery ‡: No

Intel® Secure Key‡: Yes

Intel® Control-Flow Enforcement Technology: Yes

Intel® Total Memory Encryption – Multi Key: No

Intel® AES New Instructions: Yes

Intel® Trusted Execution Technology ‡: Yes

Execute Disable Bit ‡: Yes

Intel® OS Guard: Yes

Intel® Boot Guard: Yes

Mode-based Execute Control (MBEC): Yes

Intel® Stable IT Platform Program (SIPP): No

Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡: No

Intel® Virtualization Technology (VT-x) ‡: Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes

Intel® VT-x with Extended Page Tables (EPT) ‡: Yes

Warranty

3 Years
