Watts

650W

Model

SPD-650AH2NXB

Dimension (W/H/D )

150mm(W)x86mm(H)x140mm(D)

PFC (Power Factor Correction)

Active PFC

Power Good Signal

100-150 msec

Hold Up Time

> 17msec at 80% load

Input Current

12A Max.

Input Frequency Range

50Hz – 60Hz

Input Voltage

100-240Vac

Operating Temperature

5°C to + 40°C

Operating Humidity

20% to 85%,non-condensing

Storage Temperature

-40°C to + 55°C

Storage Humidity

10% to 95%, non-condensing

Cooling System

120mm Hydraulic Bearing Fan

Efficiency

Meet 80 PLUS® Bronze at 115Vac input.

MTBF

100,000 hrs minimum

Safety Approval

CE/UKCA/LVD/FCC/ICES/TUV/CB/cTUVus/BSMI

PCI-E 6+2pin

2

Protection

OCP/OVP/OPP/OTP/SCP/UVP

Warranty

5 Years

Note*

Price, feature and specifications are subject to change without notice.
