Product Name

HAF 700

Product Code

H700-IGNN-S00

Exterior Color

Titanium Grey

Materials

Exterior: Steel, Plastic

Left Side Panel: Tempered Glass, Steel, Plastic

Dimensions(L x W x H)

556 x 279 x 540 mm (Body Size), 666 x 291 x 626 mm (incl. Protrusions)

Motherboard Support

Mini ITX, Micro ATX, ATX, E-ATX, SSI CEB, SSI EEB

Expansion Slots

8

2.5″” / 3.5″” Drive Bays (Combo)

9 (4*HDD bracket, 5*Screw+Rubber)

I/O Panel

1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0)

1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack

Pre-installed Fan(s)

Front = 2x SickleFlow 200 ARGB PWM

Rear = 2x SickleFlow 120 ARGB PWM

Bottom = 1x SickleFlow 120 ARGB PWM

Fan Support

Top = 2x 200mm, 3x 140mm, 6x 120mm (Remove 480mm bracket)

Front = 2x 200mm

Rear = 2x 120mm

Bottom = 3x 120/140mm

Side = 4x 120mm / 3 x 140mm

Radiator Support

Top = Up to 2x 360mm / 1x 420mm

Rear = Up to 240mm

Bottom = Up to 420/360mm

Side = Up to 480/420/360mm

Clearances

Clearance – CPU Cooler = 166mm / 6.53 inch

Clearance – PSU = 200mm / 7.87 inch

Clearance – GFX = 490mm / 19.29 inch

Cable Routing

Behind MB Tray: 90-101mm

Additional Included Accessories

1x Rotatable Radiator Bracket, 1x LED Controller A1 (ARGB Gen2), 1x ARGB/PWM Hub

Dust Filters

Bottom, Right side

Power Supply Support

Bottom Mount, ATX

Series

HAF Series

Size

Full Tower

Warranty

2 years

Note*

Price, feature and specifications are subject to change without notice.

* For regular 30mm thick radiators, for thicker please reference compatibility sheet.
